LiTROS IG Frame Hanger
The horizontal conveyor system LiTROS IG Frame Hanger offers a robust solution for manual loading and transportation from spacer frame within the production line. The free-standing station is specially designed to receive butylated ones frame , which are hooked into the conveyor strips. The transport takes place via a manually controlled foot pedal drive up to the defined end position, where it is frame removed and fed to the next work step — setting the frame.
specifications
- Minimum frame size: 400 × 200 mm
- Maximum frame size: 3500 × 2300 mm
- Conveyor strips: 19 pieces (standard), each with 7 insert hooks
- Design: Free-standing, without lift function
Components of system:
Free-standing transport station
Conveyor strips with insert hooks
foot pedal drive for manual control
LiTROS Insulating Stand Alone
highlights
01
Flexible frame mount:
19 conveyor strips, each with 7 hooks, make it possible to accommodate different frame formats.
Manual control:
Precise transport thanks to foot pedal drive.
Robust construction:
Free-standing construction without lift function for easy integration.
Production optimization:
Efficient transfer of work frame to the next work step.
Perfectly coordinated
Function & procedure
01
function
After they have been attached to the spacer frame hooks of the conveyor strips, the transport process is manually controlled via the foot pedal.
02
transportation
They frame are guided to the end position, where they are made available for the next production step.
03
servicing
system It requires little maintenance and is suitable for various frame sizes.
